This is Aluminium Electrolytic Capacitor 2200μF 100V dc 36mm Can - Screw Terminals Radial ALS40 Series manufactured by KEMET. The manufacturer part number is ALS40A222DB100. Its diameter is 36mm. The given dimensions of the product include 36 x 62mm. The product is available in screw terminal configuration. The product als40, is a highly preferred choice for users. In addition, the height is 62mm. It provides a 2200µf of capacitance value. Its accurate length is 62mm. It carries a 100v dc of voltage. It has a maximum operating temperature of +105°c. It features ±20% of tolerance value. Whereas, the minimum operating temperature of the product is -40°c. This product use aluminium electrolytic technology. It is assigned with possible HTSUS value of 8532.22.0055. It carries ESR (Equivalent Series Resistance) of 56mohm @ 100hz. The product features a [Ploarization] polarity. It provides a 2200 µf of capacitance value. The product has -40°c ~ 105°c operating temperature range. Moreover, the product comes in [Package/ Case]. It also exhibits voltage rating of 100 v. It has the maximum seated height of 2.441" (62.00mm) Additionally, it carries a ripple current and high frequency of 5.5 a @ 10 khz. In addition, it is reach unaffected. Its ripple current at low frequency is 4.8 a @ 100 hz. The product is widely employed in general purpose. It has an impedance value of 44 mohms. It is shipped in box. The product's diameters include 1.417" dia (36.00mm). It has a long 38 weeks standard lead time. Its typical moisture sensitivity level is not applicable. The product is available in chassis mount configuration. This product offers longer life span for 6000 hrs @ 105°c. It is assigned with 0.504" (12.80mm) of lead spacing. Moreover, it corresponds to als40a, a base product number of the product. The product is designated with the ear99 code number
For more information please check the datasheets.
