Maximum Low Level Output Current:
32mA
Dimensions:
3.15 x 2.9 x 1.2mm
Mounting Type:
Surface Mount
Maximum Propagation Delay Time @ Maximum CL:
10.8 ns @ 30 pF
Minimum Operating Supply Voltage:
1.65 V
Logic Family:
LVC
Height:
1.2mm
Width:
2.9mm
Length:
3.15mm
Package Type:
SM
Propagation Delay Test Condition:
30pF
Minimum Operating Temperature:
-40 °C
Maximum Operating Supply Voltage:
5.5 V
Maximum Operating Temperature:
+125 °C
Pin Count:
8
Maximum High Level Output Current:
-32mA
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-40°C ~ 125°C (TA)
Input Type:
-
Package / Case:
8-LSSOP, 8-MSOP (0.110", 2.80mm Width)
Number of Bits per Element:
1
REACH Status:
REACH Unaffected
Output Type:
3-State
Package:
Tape & Reel (TR)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
6 Weeks
Mounting Type:
Surface Mount
Series:
74LVC
Logic Type:
Buffer, Non-Inverting
Supplier Device Package:
SM8
Voltage - Supply:
1.65V ~ 5.5V
Current - Output High, Low:
32mA, 32mA
Number of Elements:
2
Base Product Number:
74LVC2G126
ECCN:
EAR99
