Capacitance:
110.2pF/m
Terminated/Unterminated:
Unterminated
Outer Diameter:
0.3mm
Attenuation:
0.7 dB/m @ 10 MHz
Shielding:
Tinned Copper Spiral
Standards Met:
CE EU Directive 2011/65/EU, CSA, REACH Regulation EC 1907/2006, UL
Core Strands:
7/0.025
Conductor Strand Type:
Stranded
Maximum Operating Temperature:
+150°C
Velocity ratio:
70%
Operating Temperature Range:
-70 → +150 °C
Length:
100m
Coaxial Type:
Micro Coax
Number of Strands:
7
Characteristic Impedance:
50 Ω
Sheath Material:
Perfluoroalkoxy (PFA)
Conductor Material:
Silvered Copper
Size of Strands:
0.025 mm
Sheath Colour:
White
Minimum Operating Temperature:
-70°C
Insulation Material:
PFA
HTSUS:
8544.20.0000
RoHS Status:
ROHS3 Compliant
Jacket (Insulation) Material:
Perfluoroalkoxy (PFA)
Dielectric Diameter:
-
Conductor Strand:
7 Strands / 50 AWG
Operating Temperature:
-70°C ~ 150°C
Usage:
-
Dielectric Material:
Perfluoroalkoxy (PFA)
VoP, Velocity of Propagation:
70
REACH Status:
REACH Unaffected
Impedance:
50 Ohms
Cable Group:
-
Package:
Spool
Wire Gauge:
42 AWG
Shield Type:
Spiral
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
328.1' (100.00m)
standardLeadTime:
20 Weeks
Shield Coverage:
90%
Features:
-
Jacket (Insulation) Diameter:
0.012" (0.31mm)
Conductor Material:
Copper Alloy, Silver Coated
Series:
-
Cable Type:
Micro Coaxial
Shield Material:
Copper, Tinned
ECCN:
EAR99
Base Product Number:
9442
Jacket Color:
White
