Series:
D-Sub
Current Rating:
6.5A
Dimensions:
39.2 x 12.55 x 18.2mm
Mounting Type:
Through Hole
Gender:
Male
Body Orientation:
Right Angle
Termination Method:
Solder
Length:
39.2mm
D Connector Type:
Standard D-Sub
Housing Material:
Glass Fibre Reinforced Thermoplastic
Width:
12.55mm
Depth:
18.2mm
Mixed Contact Layout:
15W2
Minimum Operating Temperature:
-55.0°C
Pitch:
2.77 mm, 2.84mm
Mounting Hardware:
4-40 UNC Screwlocks
Number of Contacts:
15
Maximum Operating Temperature:
+125°C
Contact Material:
Copper Alloy
Shell Size, Connector Layout:
2 (DA, A)
Flange Feature:
Mating Side, Female Screwlock (4-40)
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 125°C
Connector Style:
D-Sub
Contact Finish Thickness:
30.0µin (0.76µm)
Dielectric Material:
Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Number of Positions:
15
Voltage Rating:
-
REACH Status:
REACH Unaffected
Number of Rows:
2
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Wire Gauge:
-
Contact Form:
Stamped
Connector Type:
Plug, Male Pins
Contact Finish:
Gold or Gold-Palladium
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Termination:
Solder
standardLeadTime:
8 Weeks
Current Rating (Amps):
6.5A
Backset Spacing:
0.318" (8.08mm)
Ingress Protection:
-
Features:
Board Lock, Grounding Indents
Mounting Type:
Through Hole, Right Angle
Color:
-
Series:
-
Shell Material, Finish:
Steel
Contact Type:
Signal
Contact Material:
Copper Alloy
ECCN:
EAR99
