Number of Levels:
Single
Standards Met:
CCC, CSA, cUL Recognized, DNV GL, IEC 60947-7-2, IEC/EN 60079-7, KR, LR, NEPSI, VDE
Series:
ST 2.5-QUATTRO-PE
Colour:
Green/Yellow
Model Number:
5-QUATTRO-PE, ST 2
Hazardous Area Certification:
ATEX, EAC Ex, IECEx
American Wire Gauge:
28 → 12AWG
Minimum Operating Temperature:
-60°C
Termination Method:
Spring Cage
Cable CSA:
2.5mm²
Maximum Operating Temperature:
+105°C
HTSUS:
8536.69.8000
RoHS Status:
RoHS Compliant
Termination Style:
Push In, Spring
Material - Insulation:
Polyamide (PA), Nylon
Type:
Ground, Earth
Number of Positions:
4
Wire Gauge or Range - mm²:
0.08-4mm²
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Stripping Length:
10mm
Moisture Sensitivity Level (MSL):
Not Applicable
Wire Gauge or Range - AWG:
12-28 AWG
Voltage - UL:
-
standardLeadTime:
8 Weeks
Terminal - Width:
5.2mm
Disconnect Type:
-
Voltage - IEC:
-
Features:
-
Color:
Green, Yellow
Series:
CLIPLINE ST
Fuse Type:
-
Number of Levels:
1
ECCN:
EAR99
