Colour:
White
Series:
SSK 116 KER-EX
Cable CSA:
0.5 → 16mm²
Model Number:
SSK 116 KER-EX
Standards Met:
CCC, CSA, EAC Ex, GL, UKCA
Current Rating:
57A
Voltage Rating:
630 V
Number of Levels:
Single
Termination Method:
Screw
American Wire Gauge:
20 → 6AWG
Hazardous Area Certification:
ATEX, IECEx
Maximum Operating Temperature:
+180°C
Minimum Operating Temperature:
-60°C
Number of Levels:
Single
Current Rating:
57A
Standards Met:
CCC, CSA, EAC Ex, GL, UKCA
Voltage Rating:
630 V
Series:
SSK 116 KER-EX
Colour:
White
Model Number:
SSK 116 KER-EX
Hazardous Area Certification:
ATEX, IECEx
American Wire Gauge:
20 → 6AWG
Minimum Operating Temperature:
-60°C
Termination Method:
Screw
Cable CSA:
0.5 → 16mm²
Maximum Operating Temperature:
+180°C
HTSUS:
8536.69.8000
RoHS Status:
ROHS3 Compliant
Termination Style:
Screw
Material - Insulation:
Ceramic, Keramik
Type:
Feed Through
Number of Positions:
2
Wire Gauge or Range - mm²:
0.5-16mm²
REACH Status:
REACH Unaffected
Package:
Bulk
Stripping Length:
11mm
Moisture Sensitivity Level (MSL):
Not Applicable
Current - IEC:
57 A
Wire Gauge or Range - AWG:
6-20 AWG
standardLeadTime:
8 Weeks
Terminal - Width:
10.4mm
Voltage - IEC:
800V
Features:
Explosion Proof, Harsh Environment
Color:
White
Series:
CLIPLINE SSK
Number of Levels:
1
ECCN:
EAR99
