Colour:
Grey
Series:
UK 10 N
Cable CSA:
0.5 → 10mm²
Model Number:
UK 10 N
Standards Met:
CCC, CSA, cULus Recognized, EAC Ex, GL, IEC 60947-7-1, UL
Current Rating:
76A
Voltage Rating:
800 V
Number of Levels:
Single
Termination Method:
Screw
American Wire Gauge:
20 → 6AWG
Hazardous Area Certification:
ATEX
Maximum Operating Temperature:
+105°C
Minimum Operating Temperature:
-60°C
Number of Levels:
Single
Current Rating:
76A
Standards Met:
CCC, CSA, cULus Recognized, EAC Ex, GL, IEC 60947-7-1, UL
Voltage Rating:
800 V
Series:
UK 10 N
Colour:
Grey
Model Number:
UK 10 N
Hazardous Area Certification:
ATEX
American Wire Gauge:
20 → 6AWG
Minimum Operating Temperature:
-60°C
Termination Method:
Screw
Cable CSA:
0.5 → 10mm²
Maximum Operating Temperature:
+105°C
HTSUS:
8536.69.8000
RoHS Status:
RoHS Compliant
Termination Style:
Screw
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
2
Wire Gauge or Range - mm²:
0.5-16mm²
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Stripping Length:
10mm
Moisture Sensitivity Level (MSL):
Not Applicable
Current - IEC:
57 A
Wire Gauge or Range - AWG:
6-24 AWG
Voltage - UL:
600V
standardLeadTime:
15 Weeks
Terminal - Width:
10.2mm
Voltage - IEC:
800V
Color:
Gray
Series:
CLIPLINE UK
Current - UL:
65 A
Number of Levels:
1
ECCN:
EAR99
