Fused:
No
Colour:
Grey
Series:
PTPOWER 35
Cable CSA:
35mm²
Model Number:
PTPOWER 35
Standards Met:
CCC, CSA, cULus, DNV, EAC
Current Rating:
109A
Voltage Rating:
1 kV
Number of Levels:
Single
Termination Method:
Push In
American Wire Gauge:
2AWG
Hazardous Area Certification:
ATEX, IECEx
Maximum Operating Temperature:
+105°C
Minimum Operating Temperature:
-60°C
Current Rating:
109A
Number of Levels:
Single
Fused:
No
Standards Met:
CCC, CSA, cULus, DNV, EAC
Voltage Rating:
1 kV
Series:
PTPOWER 35
Colour:
Grey
Model Number:
PTPOWER 35
Hazardous Area Certification:
ATEX, IECEx
American Wire Gauge:
2AWG
Minimum Operating Temperature:
-60°C
Termination Method:
Push In
Cable CSA:
35mm²
Maximum Operating Temperature:
+105°C
HTSUS:
8536.69.8000
RoHS Status:
RoHS Compliant
Termination Style:
Push In, Spring
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
2
Wire Gauge or Range - mm²:
2.5-35mm²
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Stripping Length:
25mm
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
125 A
Wire Gauge or Range - AWG:
2-14 AWG
Voltage - UL:
1000V
standardLeadTime:
8 Weeks
Terminal - Width:
16.0mm
Voltage - IEC:
1000V
Color:
Gray
Series:
CLIPLINE PTPOWER
Current - UL:
115 A
Number of Levels:
1
ECCN:
EAR99
