Maximum Frequency Range Square Pulse and Arbitrary Waveform:
50MHz
Dimensions:
50 x 50 x 15mm
Width:
50mm
Variable Sweep:
Yes
CMOS Output Level:
1.6 → 5V
Maximum Frequency Range Sinewave:
200MHz
Minimum Frequency Range Sinewave:
10kHz
Model Number p:
SQ200
Maximum Operating Temperature:
+40°C
FM Modulation:
Yes
Length:
50mm
Interface Type:
USB
Time Base Accuracy:
50ppm
Minimum Frequency Range Square Pulse and Arbitrary Waveform:
1 Hz
Input Impedance:
100 kΩ
Digital Frequency:
Yes
Weight:
80g
TTL Output Level:
1.6 → 5V
Frequency Range Square Pulse and Arbitrary Waveform:
1 Hz → 50 MHz
Height:
15mm
Internal Linear and Log Sweep:
Yes
Output Impedance:
270Ω
Minimum Operating Temperature:
-10°C
Tool Type:
Logic Analyzer
HTSUS:
9027.90.2000
Weight:
-
Package:
Box
Specifications:
4 Channel
Series:
ScanaQuad
RoHS Status:
ROHS3 Compliant
REACH Status:
REACH Unaffected
Moisture Sensitivity Level (MSL):
Not Applicable
For Use With/Related Products:
Communication Systems, Computer Systems, Electrical Systems
ECCN:
3A992
