Maximum Low Level Output Current:
4.2mA
Maximum High Level Output Current:
-4.2mA
Dimensions:
19.3 x 6.35 x 4.57mm
Mounting Type:
Through Hole
Number of Inputs per Gate:
8
Minimum Operating Supply Voltage:
3 V
Logic Function:
AND/NAND
Logic Family:
4000
Height:
4.57mm
Width:
6.35mm
Length:
19.3mm
Package Type:
PDIP
Propagation Delay Test Condition:
50pF
Minimum Operating Temperature:
-55 °C
Maximum Propagation Delay Time @ Maximum CL:
110 ns @ 15 V, 150 ns @ 10 V, 300 ns @ 5 V
Schmitt Trigger Input:
No
Number of Elements:
1
Maximum Operating Temperature:
+125 °C
Pin Count:
14
Maximum Operating Supply Voltage:
18 V
Number of Inputs:
8
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 125°C
Package / Case:
14-DIP (0.300", 7.62mm)
Output Type:
Single-Ended
Package:
Tube
standardLeadTime:
6 Weeks
Number of Circuits:
1
Mounting Type:
Through Hole
Series:
4000B
Logic Type:
AND/NAND Gate
Supplier Device Package:
14-PDIP
Voltage - Supply:
3V ~ 18V
Current - Output High, Low:
6.8mA, 6.8mA
Schmitt Trigger Input:
No
ECCN:
EAR99
