Typical Dual Supply Voltage:
±12 V, ±15 V, ±18 V, ±5 V, ±9 V
Typical Input Voltage Noise Density:
25nV/√Hz
Typical Gain Bandwidth Product:
20MHz
Dimensions:
4.9 x 3.91 x 1.58mm
Mounting Type:
Surface Mount
Typical Slew Rate:
25V/µs
Power Supply Type:
Dual
Number of Channels per Chip:
1
Rail to Rail:
No
Height:
1.58mm
Width:
3.91mm
Length:
4.9mm
Package Type:
SOIC
Minimum Operating Temperature:
-25 °C
Amplifier Type:
Precision
Typical Voltage Gain:
100 dB
Maximum Operating Temperature:
+85 °C
Pin Count:
8
HTSUS:
8542.33.0001
Current - Output / Channel:
35 mA
Operating Temperature:
-40°C ~ 85°C
Package / Case:
8-SOIC (0.154", 3.90mm Width)
Current - Input Bias:
50 pA
Voltage - Supply Span (Max):
48 V
Voltage - Supply Span (Min):
9 V
Output Type:
Differential
Current - Supply:
5.3mA
Package:
Bulk
Slew Rate:
25V/µs
Voltage - Input Offset:
1 mV
Number of Circuits:
1
Gain Bandwidth Product:
20 MHz
Mounting Type:
Surface Mount
Series:
-
Supplier Device Package:
8-SOIC
Amplifier Type:
General Purpose
ECCN:
EAR99
