Typical Input Voltage Noise Density:
30nV/√Hz
Typical Gain Bandwidth Product:
1MHz
Dimensions:
8.75 x 4 x 1.65mm
Mounting Type:
Surface Mount
Typical Slew Rate:
0.8V/µs
Power Supply Type:
Single
Number of Channels per Chip:
4
Rail to Rail:
Rail to Rail Input/Output
Height:
1.65mm
Typical Single Supply Voltage:
3 → 15 V
Width:
4mm
Length:
8.75mm
Package Type:
SOIC
Minimum Operating Temperature:
-40 °C
Amplifier Type:
Low Power
Typical Voltage Gain:
92 dB
Maximum Operating Temperature:
+125 °C
Pin Count:
14
HTSUS:
8542.33.0001
RoHS Status:
ROHS3 Compliant
Current - Output / Channel:
60 mA
Operating Temperature:
-40°C ~ 125°C
Package / Case:
14-SOIC (0.154", 3.90mm Width)
Current - Input Bias:
1 pA
Voltage - Input Offset:
10 mV
Voltage - Supply Span (Max):
16 V
Voltage - Supply Span (Min):
2.7 V
REACH Status:
REACH Unaffected
Output Type:
Rail-to-Rail
Current - Supply:
230µA
Package:
Tube
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Slew Rate:
1V/µs
standardLeadTime:
45 Weeks
Number of Circuits:
4
Gain Bandwidth Product:
1.4 MHz
Mounting Type:
Surface Mount
Series:
Automotive, AEC-Q100
Supplier Device Package:
14-SO
Amplifier Type:
CMOS
Base Product Number:
TS914
ECCN:
EAR99
