Mounting Type:
Through Hole
Maximum Continuous Forward Current:
2 x 60A
Peak Non-Repetitive Forward Surge Current:
550A
Maximum Forward Voltage Drop:
1.8V
Rectifier Type:
Fast Recovery
Number of Elements per Chip:
2
Diode Type:
Rectifier
Pin Count:
8
Peak Reverse Repetitive Voltage:
600V
HTSUS:
8541.10.0080
RoHS Status:
ROHS3 Compliant
Package / Case:
ECO-PAC1
Diode Configuration:
2 Independent
REACH Status:
REACH Unaffected
Reverse Recovery Time (trr):
50 ns
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
Voltage - Forward (Vf) (Max) @ If:
1.8 V @ 60 A
Package:
Box
Voltage - DC Reverse (Vr) (Max):
600 V
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - Average Rectified (Io) (per Diode):
60A
standardLeadTime:
73 Weeks
Current - Reverse Leakage @ Vr:
200 µA @ 600 V
Mounting Type:
Chassis Mount
Series:
FRED
Supplier Device Package:
ECO-PAC1
Technology:
Standard
Base Product Number:
DSEI2X61
ECCN:
EAR99
