Current Rating:
1 A
Conductor Resistance:
<10 mΩ
Number of Cores:
4
Cable Shape:
Single Core
IP Rating:
IP67
Shielded/Unshielded:
Unshielded
Operating Temperature Range:
-25 → +80 °C
Maximum Operating Temperature:
+80°C
Voltage Rating:
60 V
Connector 1 Orientation:
Straight
Connector 1 Gender:
Female
Length:
100mm
Mounting Type:
Panel Mount
Conductor Material:
Phosphor Bronze
Series:
M5
Connector 1 Housing Gender:
Female
Connector 1 Number of Contacts:
4
Coding:
A
Minimum Operating Temperature:
-25°C
Connector 2:
Unterminated
Connector 1:
M5
HTSUS:
8544.42.9090
RoHS Status:
ROHS3 Compliant
Voltage Rating:
60V
Mounting Feature:
Bulkhead - Front Side Nut
Operating Temperature:
-25°C ~ 80°C
Shell Size, MIL:
-
Number of Positions:
4
Contact Finish - Mating:
Gold
Backshell Material, Plating:
-
Shielding:
-
Cable Opening:
-
Shell Material:
Brass
REACH Status:
REACH Unaffected
Current Rating (Amps):
1A
Applications:
Automotive, Industrial, Instrumentation
Primary Material:
Metal
Material Flammability Rating:
-
Package:
Bulk
Shell Size - Insert:
M5-4
Connector Type:
Plug, Female Sockets
Moisture Sensitivity Level (MSL):
Not Applicable
Fastening Type:
Threaded
Termination:
Wire Leads
standardLeadTime:
25 Weeks
Insert Material:
-
Orientation:
A
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
-
Mounting Type:
Panel Mount
Shell Finish:
Nickel
Color:
Silver
Series:
Buccaneer® M5
Contact Finish Thickness - Mating:
-
Contact Material:
Phosphor Bronze
Base Product Number:
PXMBNI
ECCN:
EAR99
