Dimensions:
35.6 x 77.5 x 97mm
Mounting Type:
DIN Rail
Series:
VAL-MS-T1/T2 48/12.5/1+1V-FM
Length:
35.6mm
Height:
97mm
Depth:
77.5mm
Minimum Operating Temperature:
-40°C
Maximum Voltage Rating:
75 V ac, 100 V dc, 250 V ac
Maximum Surge Current:
30kA
Maximum Operating Temperature:
+80°C
Suppressor Type:
Lightning Arrester
HTSUS:
8536.30.8000
RoHS Status:
RoHS Compliant
Voltage - Continuous Operating (Max) (MCOV):
100VDC
Operating Temperature:
-40°C ~ 80°C
Approval Agency:
CB, CCA, cUL, cULus, EAC, KEMA-KEUR, UL, VDE
Type:
Type 1, Type 2
Current - Short Circuit Rating (SCRR):
25 kA
Form:
Module Only
Voltage - Protection Level (VP) (2416):
800 V
Current - Discharge (Nom) (8/20µS):
12.5 kA
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
8 Weeks
Features:
Remote Signaling Contacts
Mounting Type:
DIN Rail
Series:
-
Current - Discharge (Max) (8/20µS):
30 kA
Number of Poles:
2
ECCN:
EAR99
