Dimensions:
52.4 x 17.5 x 55.3mm
Mounting Type:
DIN Rail
Series:
VAL-MS
Length:
52.4mm
Height:
55.3mm
Depth:
17.5mm
Minimum Operating Temperature:
-40°C
Maximum Voltage Rating:
500 V ac
Maximum Surge Current:
30kA
Maximum Operating Temperature:
+80°C
Suppressor Type:
Surge Arrester Protection Module
HTSUS:
8536.30.8000
RoHS Status:
RoHS Compliant
Voltage - Continuous Operating (Max) (MCOV):
600VAC
Operating Temperature:
-40°C ~ 80°C
Approval Agency:
CB, CCA, CSA, cUL, cULus, GL, GOST, KEMA, OVE, UL
Type:
Type 2
Current - Short Circuit Rating (SCRR):
25 kA
Form:
Module Only
Voltage - Protection Level (VP) (2416):
2.7 kV
Current - Discharge (Nom) (8/20µS):
15 kA
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
8 Weeks
Features:
-
Mounting Type:
Base Mount
Series:
-
Current - Discharge (Max) (8/20µS):
30 kA
Number of Poles:
2
ECCN:
EAR99
