Maximum Low Level Output Current:
200mA
Timer Type:
Adjustable and Monostable
Dimensions:
10.16 x 6.6 x 4.57mm
Mounting Type:
Through Hole
Maximum Propagation Delay Time @ Maximum CL:
300 ns @ 15 pF
Minimum Operating Supply Voltage:
4.5 V
Height:
4.57mm
Number of Internal Timers:
1
Width:
6.6mm
Length:
10.16mm
Package Type:
PDIP
Propagation Delay Test Condition:
15pF
Minimum Operating Temperature:
0 °C
Maximum Operating Supply Voltage:
16 V
Maximum Operating Temperature:
+70 °C
Pin Count:
8
Maximum High Level Output Current:
-200mA
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Operating Temperature:
0°C ~ 70°C
Package / Case:
8-DIP (0.300", 7.62mm)
Type:
555 Type, Timer/Oscillator (Single)
REACH Status:
REACH Unaffected
Current - Supply:
10 mA
Count:
-
Package:
Tube
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
6 Weeks
Mounting Type:
Through Hole
Series:
-
Supplier Device Package:
8-PDIP
Frequency:
100kHz
Voltage - Supply:
4.5V ~ 16V
Base Product Number:
NE555
ECCN:
EAR99
