This is manufactured by Nichicon. The manufacturer part number is UPM1V101MPD. Its diameter is 8mm. The given dimensions of the product include 8 (dia.) x 11.5mm. The product is available in radial, through hole configuration. The product upm, is a highly preferred choice for users. It provides a 100µf of capacitance value. Its accurate length is 11.5mm. It carries a 35v dc of voltage. It has a maximum operating temperature of +105°c. This product use aluminium electrolytic technology. It is assigned with possible HTSUS value of 8532.22.0020. The product is rohs3 compliant. The product features a [Ploarization] polarity. It provides a 100 µf of capacitance value. The product has -55°c ~ 105°c operating temperature range. Moreover, the product comes in [Package/ Case]. It features ±20% of tolerance value. It also exhibits voltage rating of 35 v. It has the maximum seated height of 0.512" (13.00mm) Additionally, it carries a ripple current and high frequency of 460 ma @ 10 khz. In addition, it is reach unaffected. Its ripple current at low frequency is 305 ma @ 120 hz. The product is widely employed in general purpose. It has an impedance value of 160 mohms. It is shipped in bulk. The product's diameters include 0.315" dia (8.00mm). Its typical moisture sensitivity level is not applicable. The product is available in through hole configuration. This product offers longer life span for 3000 hrs @ 105°c. It is assigned with 0.138" (3.50mm) of lead spacing. The product is designated with the ear99 code number
For more information please check the datasheets.
