Diameter:
65mm
Ripple Current:
12.4 (A @100 Hz 85°C), 40.1 (A @10 kHz 40°C), 57.3 (A @10 kHz 50°C)
Polarised:
Polar
Dimensions:
65 x 105mm
Mounting Type:
Screw Terminal
Series:
PEH200
Equivalent Series Resistance:
10 mΩ @ 100 kHz, 24 mΩ @ 100 Hz
Height:
105mm
Capacitance:
2700µF
Length:
105mm
Voltage:
420V dc
Leakage Current:
7.402 μA
Lifetime:
15000 h @ +85 °C/420V dc/Ir
Lead Pitch:
28.5mm
Maximum Operating Temperature:
+85°C
Tolerance:
±20%
Minimum Operating Temperature:
-40°C
Technology:
Aluminium Electrolytic
Manufacturer Standard Lead Time:
20 Weeks
Detailed Description:
2700µF 420V Aluminum Electrolytic Capacitors Radial, Can - Screw Terminals 24 mOhm @ 100Hz 15000 Hrs @ 85°C
Voltage - Rated:
420V
ESR (Equivalent Series Resistance):
24 mOhm @ 100Hz
Polarization:
Polar
Capacitance:
2700µF
Operating Temperature:
-40°C ~ 85°C
Package / Case:
Radial, Can - Screw Terminals
Tolerance:
±20%
Height - Seated (Max):
4.213" (107.00mm)
Ripple Current @ Low Frequency:
12.4A @ 100Hz
Applications:
General Purpose
Standard Package:
16
Impedance:
12 mOhms
Manufacturer:
KEMET
Size / Dimension:
2.622" Dia (66.60mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Mounting Type:
Chassis Mount
Series:
PEH200
Packaging:
Bulk
Lifetime @ Temp.:
15000 Hrs @ 85°C
Lead Spacing:
1.122" (28.50mm)
Other Names:
399-5647
A451QM272M420A
