Manufacturer Standard Lead Time:
11 Weeks
Detailed Description:
Power Barrel Connector Jack 2.50mm ID (0.098"), 5.50mm OD (0.217") Through Hole, Right Angle
Actual Diameter:
0.098" (2.50mm ID), 0.224" (5.70mm OD)
Voltage - Rated:
24VDC
Housing Material:
Polybutylene Terephthalate (PBT)
Operating Temperature:
-25°C ~ 85°C
Contact Material - Plating:
Tin
Shielding:
Unshielded
Number of Positions/Contacts:
2 Conductors, 3 Contacts
Internal Switch(s):
Single Switch, Normally Closed
Industry Recognized Mating Diameter:
2.50mm ID (0.098"), 5.50mm OD (0.217")
Material Flammability Rating:
UL94 V-0
Manufacturer:
CUI Devices
Gender:
Male
Connector Type:
Jack
Termination:
Solder Eyelet(s)
Current Rating (Amps):
2.5A
Body Color:
Black
Features:
Board Guide
Mounting Type:
Through Hole, Right Angle
Mating Length/Depth:
0.386" (9.80mm)
Packaging:
Bulk
Customer Reference:
Contact Material:
Brass, Copper Alloy
