Minimum DC Current Gain:
40
Transistor Type:
NPN
Dimensions:
9.9 x 4.5 x 15.7mm
Mounting Type:
Through Hole
Maximum Power Dissipation:
30 W
Maximum Collector Base Voltage:
100 V
Maximum Collector Emitter Voltage:
115 V
Maximum Emitter Base Voltage:
5 V
Package Type:
TO-220
Number of Elements per Chip:
1
Maximum DC Collector Current:
2 A
Maximum Operating Temperature:
+150 °C
Pin Count:
3
Transistor Configuration:
Single
Current - Collector (Ic) (Max):
2 A
HTSUS:
8541.29.0095
RoHS Status:
ROHS3 Compliant
Voltage - Collector Emitter Breakdown (Max):
100 V
Operating Temperature:
150°C (TJ)
Package / Case:
TO-220-3
DC Current Gain (hFE) (Min) @ Ic, Vce:
15 @ 1A, 4V
Frequency - Transition:
-
Vce Saturation (Max) @ Ib, Ic:
700mV @ 200mA, 1A
REACH Status:
REACH Unaffected
Transistor Type:
NPN
Package:
Tube
Moisture Sensitivity Level (MSL):
Not Applicable
standardLeadTime:
58 Weeks
Current - Collector Cutoff (Max):
300µA
Mounting Type:
Through Hole
Series:
-
Supplier Device Package:
TO-220-3
Power - Max:
30 W
Base Product Number:
BD239
ECCN:
EAR99
