Breaking Capacity at Maximum Voltage Rating:
5000 A @ 125 V dc, 5000 A @ 240 Vac
Current Rating:
100A
Mounting Hole Width:
69.9mm
Mounting Hole Size:
26.5 x 69.85mm
Circuit Breaker Type:
MCCB
Tripping Mechanism:
Hydraulic-Magnetic
Series:
E
Overall Dimensions:
26.06 x 130.18 x 82.84mm
Terminal Contact Type:
Box Wire Connector
Rated DC Voltage:
125V
Mounting Style:
Panel Mount
Application:
Generators, Ideal for Higher Current and Voltage Applications, Industrial Appliances, Military, Renewable Energy Systems
Mounting Hole Length:
26.5mm
Rated AC Voltage:
600V
Overall Length:
26.1mm
Overall Depth:
82.8mm
Special Features:
Certified for Circuit Branch Protection, CSA, Optional Power Selector Device, Recognized as a Manual Motor Controller, Recognized as a Supplementary Protector, UL
Number of Poles:
1
Reset Actuator Type:
Handle
Break Time:
Medium
HTSUS:
8536.20.0020
RoHS Status:
ROHS3 Compliant
Voltage Rating - DC:
125 V
Approval Agency:
CCC, CSA, UL489
Voltage Rating - AC:
600 V
REACH Status:
REACH Unaffected
Package:
Bulk
Breaker Type:
Magnetic (Hydraulic Delay)
standardLeadTime:
12 Weeks
Current Rating (Amps):
100A
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Illumination Voltage (Nominal):
-
Mounting Type:
Panel Mount
Series:
E
Actuator Type:
Lever
Illumination:
None
Number of Poles:
1
Base Product Number:
EA1-B0
ECCN:
EAR99
