Number of Contacts:
6
Current Rating:
8 (cUL) A, 10 (CCC) A, 10 (UL) A, 10 (VDE) A
Mating Type:
Quick Connect
Mounting Type:
Cable Mount
IP Rating:
IP66, IP68, IP69K
Gender:
Male
Body Orientation:
Straight
Voltage Rating:
500 (CCC) V ac/dc, 500 (VDE) V ac/dc, 600 (cUL) V ac/dc, 600 (UL) V ac/dc
Contact Gender:
Male
Termination Method:
Screw
Housing Material:
Zinc Alloy
Connector Size:
Standard
Contact Plating:
Nickel
Series:
PXM
Contact Material:
Brass
Maximum Operating Temperature:
+120°C
Minimum Operating Temperature:
-40°C
Series Number:
7000
HTSUS:
8536.69.4020
RoHS Status:
ROHS3 Compliant
Voltage Rating:
600V
Mounting Feature:
-
Operating Temperature:
-40°C ~ 120°C
Shell Size, MIL:
-
Number of Positions:
6 (Power)
Contact Finish - Mating:
Nickel
Backshell Material, Plating:
Zinc Alloy, Nickel
Shielding:
Unshielded
Cable Opening:
0.512" ~ 0.591" (13.00mm ~ 15.00mm)
Shell Material:
Zinc Alloy
REACH Status:
REACH Unaffected
Current Rating (Amps):
10A
Applications:
-
Primary Material:
Metal
Material Flammability Rating:
-
Package:
Bulk
Shell Size - Insert:
-
Connector Type:
Plug, Male Pins
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Bayonet Lock
Termination:
Screw
standardLeadTime:
20 Weeks
Insert Material:
-
Orientation:
Keyed
Ingress Protection:
IP66/IP68/IP69K - Dust Tight, Water Resistant, Waterproof
Features:
Backshell, Coupling Nut
Mounting Type:
Free Hanging (In-Line)
Shell Finish:
Nickel
Color:
Silver
Series:
Buccaneer® 7000
Contact Finish Thickness - Mating:
-
Contact Material:
Brass
Base Product Number:
PXM7010
ECCN:
EAR99
