Current Rating:
4.0A
Mating Type:
A Coded
Mounting Type:
Cable Mount, Panel Mount
IP Rating:
IP65, IP67, IP69K
Series:
SACC
Body Orientation:
Right Angle
Voltage Rating:
250 V
Coding:
A
Contact Gender:
Female
Termination Method:
Screw
Housing Material:
Polymer
Plug/Socket:
Socket
Connector Size:
M12
Contact Plating:
Gold
Shell Size:
M12
Number of Contacts:
4
Maximum Operating Temperature:
+85°C
Minimum Operating Temperature:
-40°C
Contact Material:
Copper
HTSUS:
8536.69.4020
RoHS Status:
RoHS Compliant
Mounting Feature:
-
Operating Temperature:
-40°C ~ 85°C
Shell Size, MIL:
-
Number of Positions:
4
Contact Finish - Mating:
Gold
Backshell Material, Plating:
Polyamide (PA), Nylon
Shielding:
-
Cable Opening:
0.157" ~ 0.236" (4.00mm ~ 6.00mm)
Voltage Rating:
250V
Current Rating (Amps):
4A
Applications:
-
Primary Material:
Metal
Material Flammability Rating:
-
Package:
Bulk
Shell Size - Insert:
M12-4
Connector Type:
Receptacle, Female Sockets
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Threaded
Shell Material:
Stainless Steel
Termination:
Screw
standardLeadTime:
4 Weeks
Insert Material:
Polyamide (PA), Nylon
Orientation:
A
Ingress Protection:
IP65/IP67/IP69K - Dust Tight, Water Resistant, Waterproof
Features:
Backshell, Coupling Nut
Mounting Type:
Free Hanging (In-Line), Right Angle
Shell Finish:
-
Color:
Black, Silver
Series:
SACC
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Zinc
ECCN:
EAR99
