HTSUS:
8536.69.4020
RoHS Status:
RoHS Compliant
Mounting Feature:
Bulkhead - Front Side Nut
Operating Temperature:
-25°C ~ 85°C
Shell Size, MIL:
-
Number of Positions:
12
Contact Finish - Mating:
Gold
Backshell Material, Plating:
-
Shielding:
-
Cable Opening:
-
Voltage Rating:
30VAC, 42VDC
Current Rating (Amps):
2A
Applications:
Industrial, Telecommunications
Primary Material:
Metal
Material Flammability Rating:
UL94 V-0
Package:
Tray
Shell Size - Insert:
10
Connector Type:
Receptacle, Female Sockets
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Bayonet Lock
Shell Material:
Zinc Alloy
Termination:
Solder
standardLeadTime:
26 Weeks
Insert Material:
Polyphenylene Sulfide (PPS)
Orientation:
Keyed
Ingress Protection:
IP67/IP68 - Dust Tight, Waterproof
Features:
-
Mounting Type:
Panel Mount, Through Hole
Shell Finish:
Nickel
Color:
Silver
Series:
LF
Contact Finish Thickness - Mating:
8.00µin (0.203µm)
Contact Material:
Phosphor Bronze
Base Product Number:
LF10WBR
ECCN:
EAR99
