Current Rating:
12.0A
Mating Type:
Quick Connect
Mounting Type:
Panel Mount
IP Rating:
IP65, IP67
Series:
M12
Body Orientation:
Straight
Voltage Rating:
63.0 V
Contact Gender:
Female
Housing Material:
Zinc
Plug/Socket:
Socket
Connector Size:
M12
Contact Plating:
Gold
Termination Method:
Solder
Number of Contacts:
5
Maximum Operating Temperature:
+85°C
Minimum Operating Temperature:
-40°C
Contact Material:
Copper
HTSUS:
8536.69.4020
RoHS Status:
ROHS3 Compliant
Voltage Rating:
63V
Mounting Feature:
Bulkhead - Front Side Nut
Operating Temperature:
-40°C ~ 85°C
Shell Size, MIL:
-
Number of Positions:
5 (4 Power + FE)
Contact Finish - Mating:
Gold
Backshell Material, Plating:
-
Shielding:
Shielded
Cable Opening:
-
Shell Material:
Zinc Die Cast
REACH Status:
REACH Unaffected
Current Rating (Amps):
16A
Applications:
-
Primary Material:
Metal
Material Flammability Rating:
-
Package:
Bulk
Shell Size - Insert:
M12-5
Connector Type:
Plug, Female Sockets and Male Pins
Moisture Sensitivity Level (MSL):
Not Applicable
Fastening Type:
Threaded
Termination:
Solder
standardLeadTime:
15 Weeks
Insert Material:
Polyamide (PA), Nylon
Orientation:
L
Ingress Protection:
IP65/IP67 - Dust Tight, Water Resistant, Waterproof
Features:
Board Guide
Mounting Type:
Panel Mount, Through Hole
Shell Finish:
-
Color:
Silver
Series:
M12
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Alloy
ECCN:
EAR99
