HTSUS:
8536.69.4020
RoHS Status:
RoHS Compliant
Mounting Feature:
-
Operating Temperature:
-40°C ~ 105°C
Shell Size, MIL:
-
Number of Positions:
8 (5 + 3 Power)
Contact Finish - Mating:
Gold
Backshell Material, Plating:
Polyamide (PA), Nylon
Shielding:
Unshielded
Cable Opening:
0.374" ~ 0.425" (9.50mm ~ 10.80mm)
Voltage Rating:
-
Current Rating (Amps):
2A, 20A
Applications:
-
Primary Material:
Plastic
Material Flammability Rating:
-
Package:
Bulk
Shell Size - Insert:
D
Connector Type:
Plug, Female Sockets and Male Pins
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Bayonet Lock
Shell Material:
Polyamide (PA), Nylon, Glass Filled
Termination:
Solder Cup
standardLeadTime:
14 Weeks
Insert Material:
Polyamide (PA), Nylon, Glass Filled
Orientation:
Keyed
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
Backshell, Coupling Nut
Mounting Type:
Free Hanging (In-Line)
Shell Finish:
-
Color:
Black
Series:
Large
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Alloy
Base Product Number:
DCU-08BFEA
ECCN:
EAR99
