Current Rating:
7.0A
Mating Type:
Bayonet
Mounting Type:
Flange Mount
IP Rating:
IP68, IP69K
Series:
UTS
Body Orientation:
Straight
Voltage Rating:
50.0 V
Contact Gender:
Female
Termination Method:
Solder
Housing Material:
Thermoplastic
Plug/Socket:
Plug
Contact Plating:
Gold
Shell Size:
10
Number of Contacts:
7
Maximum Operating Temperature:
+105°C
Minimum Operating Temperature:
-40°C
Contact Material:
Copper
HTSUS:
8536.69.4020
RoHS Status:
ROHS3 Compliant
Voltage Rating:
250V
Mounting Feature:
Flange
Operating Temperature:
-40°C ~ 105°C
Shell Size, MIL:
-
Number of Positions:
7
Contact Finish - Mating:
Gold
Backshell Material, Plating:
-
Shielding:
Unshielded
Cable Opening:
-
Shell Material:
Polybutylene Terephthalate (PBT)
REACH Status:
REACH Unaffected
Current Rating (Amps):
6A
Applications:
Energy, Instrumentation, Lighting, Telecommunications
Primary Material:
Plastic
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Shell Size - Insert:
10-7
Connector Type:
Receptacle, Female Sockets
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Bayonet Lock
Termination:
Solder Cup
standardLeadTime:
12 Weeks
Insert Material:
Polychloroprene
Orientation:
N (Normal)
Ingress Protection:
IP68/IP69K - Dust Tight, Water Resistant, Waterproof
Features:
UV Resistant
Mounting Type:
Panel Mount
Shell Finish:
-
Color:
Black
Series:
Trim Trio® UTS Hi Seal
Contact Finish Thickness - Mating:
16.0µin (0.41µm)
Contact Material:
Brass
Base Product Number:
UTS01
ECCN:
EAR99
