Dimensions:
300 x 98 x 52mm
Power Source:
Battery
DC Current Measurement Resolution:
10mA
Maximum Conductor Size:
58mm
Width:
98mm
Battery Life:
100 h
Resistance Measurement Resolution:
100mΩ
AC Current Measurement Resolution:
10mA
True RMS:
Yes
Absolute Maximum AC Voltage Measurement:
600V ac
Model Number:
355
Best AC Voltage Accuracy:
±(1% rdg +5 Digits)
Absolute Maximum AC Current Measurement:
2kA ac
Battery Type:
AA
Absolute Maximum Resistance Measurement:
400kΩ
Maximum Operating Temperature:
+50°C
Jaw Capacity Busbars:
58mm
Safety Category Level:
CAT IV, CAT III
Length:
300mm
Absolute Maximum DC Current Measurement:
2kA dc
Display Type:
LCD
Best Resistance Measurement Accuracy:
±1.5% +5 Digits
Best DC Current Accuracy:
±(1.5% rdg +5 Digits)
Weight:
814g
AC Voltage Measurement Resolution:
1mV
Best AC Current Accuracy:
±(1.5% rdg +5 Digits)
Safety Category Voltage:
600 V, 1000 V
Absolute Maximum DC Voltage Measurement:
1000V dc
Height:
52mm
Safety Category:
CAT III 1000 V, CAT IV 600 V
Best DC Voltage Accuracy:
±(1% rdg +5 Digits)
DC Voltage Measurement Resolution:
1mV
Clamp Meter Type:
AC/DC Clamp Meter
Minimum Operating Temperature:
0°C
Functions Measured:
AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Frequency, Resistance
