Dimensions:
243 x 96 x 43mm
Power Source:
Battery
DC Current Measurement Resolution:
0.1µA
Temperature Measurement Resolution:
0.2°C
DC Current Measurement Range:
0.1 → 600 A
AC Current Measurement Range:
0.1 → 600 A
Width:
96mm
Resistance Measurement Resolution:
0.01Ω
AC Current Measurement Resolution:
0.1µA
Best Temperature Measurement Accuracy:
±1 °C
True RMS:
Yes
AC Voltage Measurement Range:
0.001 → 600 V
Absolute Maximum AC Voltage Measurement:
600V ac
Model Number:
770-3
Best AC Voltage Accuracy:
±(1% rdg + 3dgts)
Connectivity:
Bluetooth
Absolute Maximum AC Current Measurement:
600A ac
Battery Type:
AAA
Absolute Maximum Resistance Measurement:
60MΩ
Maximum Operating Temperature:
+50°C
Minimum Operating Temperature:
-10°C
Safety Category Level:
CAT 3, CAT 4
Length:
243mm
Absolute Maximum Temperature Measurement:
+500°C
Absolute Maximum DC Current Measurement:
600A dc
Display Type:
LCD
Best Resistance Measurement Accuracy:
±(1.5 % of mv + 3 Digit)
Best DC Current Accuracy:
±(2% rdg + 5dgts)
Weight:
302g
AC Voltage Measurement Resolution:
1mV
Best AC Current Accuracy:
±(1.5% rdg + 5dgts)
Safety Category Voltage:
600 V, 1000 V
Absolute Maximum DC Voltage Measurement:
600V dc
Height:
43mm
Safety Category:
CAT 4 600 V, CAT 3 1000 V
Best DC Voltage Accuracy:
±(0.8% rdg + 3dgts)
DC Voltage Measurement Resolution:
1mV
Clamp Meter Type:
AC/DC Clamp Meter
Functions Measured:
AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Frequency, Resistance, Temperature
