Dimensions:
225 x 77.1 x 38.6mm
Power Source:
Battery
DC Current Measurement Resolution:
10nA
Maximum Conductor Size:
35mm
Width:
77.1mm
Battery Life:
200 (Backlight Off) h, 40 (Backlight On) h
Resistance Measurement Resolution:
100mΩ
AC Current Measurement Resolution:
10nA
Best Temperature Measurement Accuracy:
±1% + 2 °C
True RMS:
Yes
Absolute Maximum AC Voltage Measurement:
600V ac
Model Number:
U1194A
Best AC Voltage Accuracy:
±(1.2% rdg + 5dgts)
Absolute Maximum AC Current Measurement:
600A ac
Battery Type:
AAA
Absolute Maximum Resistance Measurement:
60kΩ
Maximum Operating Temperature:
+50°C
Non-Contact Voltage Detector:
Yes
Jaw Capacity Busbars:
35mm
Safety Category Level:
CAT IV, CAT III
Length:
225mm
Temperature Measurement Resolution:
0.1°C
Absolute Maximum Temperature Measurement:
+1200°C
Absolute Maximum DC Current Measurement:
600A dc
Display Type:
LCD
Best Resistance Measurement Accuracy:
±0.8% + 3 Digits
Best DC Current Accuracy:
±(1% rdg + 5dgts)
Weight:
348g
AC Voltage Measurement Resolution:
10mV
Best AC Current Accuracy:
±(1% rdg + 5dgts)
Safety Category Voltage:
300 V, 600 V
Absolute Maximum DC Voltage Measurement:
600V dc
Height:
38.6mm
Safety Category:
CAT III 600 V, CAT IV 300 V
Best DC Voltage Accuracy:
±(0.5% rdg + 3dgts)
DC Voltage Measurement Resolution:
10mV
Clamp Meter Type:
AC/DC Clamp Meter
Minimum Operating Temperature:
-10°C
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature
