Width:
106 mm
Height:
43mm
Length:
260mm
Weight:
525g
True RMS:
Yes
Battery Life:
60h
Display Type:
LCD
Model Number:
U1212A
Power Source:
Battery
Product Type:
Clamp Meter
Clamp Meter Type:
AC/DC Clamp Meter
Functions Measured:
Frequency, DC Voltage, Resistance, Capacitance, Diode, AC Current, Temperature, Peak, AC Voltage, Continuity
AC Current Accuracy:
±2 % rdg + 5 Digits
AC Voltage Accuracy:
±1 % rdg + 5 Digits
DC Current Accuracy:
±1.5 % rdg + 3 Digits
DC Voltage Accuracy:
±0.5 % rdg + 3 Digits
Maximum Jaw Opening:
52 mm
Standards/Approvals:
CE, CSA
Distrelec Product Id:
176-43-521
AC Current Resolution:
10mA
AC Voltage Resolution:
100mV
DC Current Resolution:
10mA
DC Voltage Resolution:
100 mV
Resistance Resolution:
100mΩ
Safety Category Level:
CAT IV, CAT III
Maximum Conductor Size:
52 mm
Temperature Resolution:
0.1°C
Safety Category Voltage:
1000V
Non-Contact Voltage Detector:
Yes
Maximum Operating Temperature:
50°C
Minimum Operating Temperature:
-10°C
Maximum AC Current Measurement:
1000A
Maximum AC Voltage Measurement:
1000V
Maximum DC Current Measurement:
1000A
Maximum DC Voltage Measurement:
1000V
Maximum Resistance Measurement:
4kΩ
Maximum Temperature Measurement:
1372°C
Resistance Measurement Accuracy:
±0.5% + 3 Digits
Temperature Measurement Accuracy:
±1 % rdg + 1 °C
