Dimensions:
207 x 75 x 34mm
Power Source:
Battery
DC Current Measurement Resolution:
10mA
Maximum Conductor Size:
30mm
Width:
75mm
Resistance Measurement Resolution:
100mΩ
AC Current Measurement Resolution:
10mA
True RMS:
Yes
Absolute Maximum AC Voltage Measurement:
600V ac
Model Number:
325
Best AC Voltage Accuracy:
±(1.5% rdg +5 Digits)
Absolute Maximum AC Current Measurement:
400A ac
Battery Type:
AAA
Absolute Maximum Resistance Measurement:
40kΩ
Maximum Operating Temperature:
+50°C
Jaw Capacity Busbars:
30mm
Safety Category Level:
CAT III, CAT IV
Length:
207mm
Temperature Measurement Resolution:
0.1°C
Absolute Maximum Temperature Measurement:
+400°C
Absolute Maximum DC Current Measurement:
400A dc
Display Type:
LCD
Best DC Current Accuracy:
±(2% rdg +5 Digits)
Weight:
283g
AC Voltage Measurement Resolution:
100mV
Best AC Current Accuracy:
±(2% rdg +5 Digits)
Safety Category Voltage:
300 V, 600 V
Absolute Maximum DC Voltage Measurement:
600V dc
Height:
34mm
Safety Category:
CAT III 600V, CAT IV 300V
Best DC Voltage Accuracy:
±(1% rdg +5 Digits)
DC Voltage Measurement Resolution:
100mV
Clamp Meter Type:
AC/DC Clamp Meter
Minimum Operating Temperature:
-10°C
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Frequency, Resistance, Temperature
