Dimensions:
224 x 77 x 37mm
Power Source:
Battery
Maximum Conductor Size:
35mm
Width:
77mm
Best Resistance Measurement Accuracy:
±1 % + 5LSD
Best Temperature Measurement Accuracy:
±1 %
True RMS:
Yes
Absolute Maximum AC Voltage Measurement:
600V ac
Model Number:
AMP 320
Best AC Voltage Accuracy:
±1 % + 5LSD
Absolute Maximum AC Current Measurement:
600A ac
Battery Type:
AAA
Absolute Maximum Resistance Measurement:
60kΩ
Maximum Operating Temperature:
+40°C
Non-Contact Voltage Detector:
Yes
Minimum Operating Temperature:
0°C
Safety Category Level:
CAT III
Length:
224mm
Calibrated:
RSCAL
Absolute Maximum Temperature Measurement:
+400°C
Absolute Maximum DC Current Measurement:
600A dc
Display Type:
LCD
Best DC Current Accuracy:
±2 % + 5LSD
Weight:
254g
Best AC Current Accuracy:
±2 % + 5LSD
Safety Category Voltage:
600V
Absolute Maximum DC Voltage Measurement:
600V dc
Height:
37mm
Safety Category:
CAT III 600 V
Best DC Voltage Accuracy:
±1 % + 5LSD
Clamp Meter Type:
AC/DC Clamp Meter
Functions Measured:
AC Current, AC Voltage, DC Current, DC Voltage, Resistance, Temperature
