Dimensions:
258 x 94 x 44mm
Power Source:
Battery
Maximum Conductor Size:
51mm
Width:
94mm
Best Resistance Measurement Accuracy:
±1 % + 5LSD
Best Temperature Measurement Accuracy:
±1 %
True RMS:
Yes
Absolute Maximum AC Voltage Measurement:
1000V ac
Model Number:
AMP 330
Best AC Voltage Accuracy:
±10 % + 5LSD
Absolute Maximum AC Current Measurement:
1kA ac
Battery Type:
AA
Absolute Maximum Resistance Measurement:
60kΩ
Maximum Operating Temperature:
+50°C
Non-Contact Voltage Detector:
Yes
Minimum Operating Temperature:
-10°C
Safety Category Level:
CAT III, CAT IV
Length:
258mm
Calibrated:
RSCAL
Absolute Maximum Temperature Measurement:
+400°C
Absolute Maximum DC Current Measurement:
1000A dc
Display Type:
LCD
Best DC Current Accuracy:
±1.8 % + 5LSD
Weight:
420g
Best AC Current Accuracy:
±2.2 % + 5LSD
Safety Category Voltage:
600 V, 1000 V
Absolute Maximum DC Voltage Measurement:
1000V dc
Height:
44mm
Safety Category:
CAT III 1000 V, CAT IV 600 V
Best DC Voltage Accuracy:
±0.8 % + 5LSD
Clamp Meter Type:
AC/DC Clamp Meter
Functions Measured:
AC Current, AC Voltage, DC Current, DC Voltage, Resistance, Temperature
