Width:
31mm
Height:
175mm
Length:
84mm
Weight:
280g
Dimensions:
84 x 31 x 175mm
Battery Life:
250 h
Battery Type:
9V, IEC 6F22, NEDA 1604
Model Number:
ICMA7-4
Power Source:
Battery
Safety Category:
CAT III 600 V
Clamp Meter Type:
AC Open Jaw Clamp Meter
Functions Measured:
AC Current, AC Voltage, Continuity, DC Voltage, Diode Test, Resistance
Jaw Capacity Busbars:
16mm
Safety Category Level:
CAT III
Maximum Conductor Size:
16 (Dia.)mm
Safety Category Voltage:
600V
Best AC Current Accuracy:
±(3% rdg + 3dgts)
Best AC Voltage Accuracy:
±(1.5% rdg + 3dgts)
Best DC Voltage Accuracy:
±(1% rdg + 2dgts)
Maximum Operating Temperature:
+50°C
Minimum Operating Temperature:
-20°C
AC Current Measurement Resolution:
100mA
AC Voltage Measurement Resolution:
1V
DC Voltage Measurement Resolution:
1V
Best Resistance Measurement Accuracy:
±1% + 2 Digits
Absolute Maximum AC Current Measurement:
200A ac
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum DC Voltage Measurement:
600V dc
Absolute Maximum Resistance Measurement:
2kΩ
