Dimensions:
145 x 42 x 24mm
Power Source:
Battery
Maximum Conductor Size:
29mm
Width:
42mm
Battery Life:
800 h
Resistance Measurement Resolution:
100mΩ
AC Current Measurement Resolution:
30mA
Absolute Maximum AC Voltage Measurement:
600V ac
Model Number:
IEK10N
Best AC Voltage Accuracy:
±(1.7% rdg + 7dgts)
Absolute Maximum AC Current Measurement:
300A ac
Battery Type:
AAA
Absolute Maximum Resistance Measurement:
30MΩ
Maximum Operating Temperature:
+50°C
Minimum Operating Temperature:
0°C
Safety Category Level:
CAT II, CAT III
Length:
145mm
Display Type:
LCD
Best Resistance Measurement Accuracy:
±3% + 5 Digits
Jaw Capacity Busbars:
29mm
Weight:
112g
AC Voltage Measurement Resolution:
1mV
Best AC Current Accuracy:
±(1.9% rdg + 0.5A)
Safety Category Voltage:
300 V, 600 V
Absolute Maximum DC Voltage Measurement:
600V dc
Height:
24mm
Safety Category:
CAT II 600 V, CAT III 300 V
Best DC Voltage Accuracy:
±(0.7% rdg + 2dgts)
DC Voltage Measurement Resolution:
100µV
Clamp Meter Type:
AC Current Clamp Meter
Functions Measured:
AC Current, AC Voltage, Continuity, DC Voltage, Diode, Resistance
