Width:
35.6mm
Height:
210mm
Length:
62mm
Weight:
200g
Dimensions:
62 x 35.6 x 210mm
Battery Type:
1.5 V
Display Type:
LCD
Model Number:
ILCM03A
Power Source:
Battery
Clamp Meter Type:
Leakage Clamp Meter
Functions Measured:
AC Current, AC Voltage, Resistance
Jaw Capacity Busbars:
30mm
Maximum Conductor Size:
30mm
Best AC Current Accuracy:
±(1% rdg + 3dgts)
Best AC Voltage Accuracy:
±(1.5% rdg + 2dgts)
Maximum Operating Temperature:
+50°C
Minimum Operating Temperature:
-10°C
AC Current Measurement Resolution:
10µA
AC Voltage Measurement Resolution:
100mV
DC Voltage Measurement Resolution:
100mV
Resistance Measurement Resolution:
100mΩ
Best Resistance Measurement Accuracy:
±1 % ± 2 Digits
Absolute Maximum AC Current Measurement:
60A ac
Absolute Maximum AC Voltage Measurement:
400V ac
Absolute Maximum Resistance Measurement:
400Ω
