Dimensions:
280 x 88 x 50mm
Power Source:
Battery
DC Current Measurement Resolution:
100mA
Maximum Conductor Size:
34mm
Width:
88mm
Resistance Measurement Resolution:
100mΩ
AC Current Measurement Resolution:
100mA
True RMS:
Yes
Absolute Maximum AC Voltage Measurement:
1 kV ac
Model Number:
381
Best AC Voltage Accuracy:
±1.5 % +5 Digits
Absolute Maximum AC Current Measurement:
2.5kA ac
Battery Type:
AA
Absolute Maximum Resistance Measurement:
60kΩ
Maximum Operating Temperature:
+50°C
Jaw Capacity Busbars:
34mm
Safety Category Level:
CAT IV, CAT III
Length:
280mm
Absolute Maximum DC Current Measurement:
1kA dc
Display Type:
LCD
Best Resistance Measurement Accuracy:
±1 % +5 Digits
Best DC Current Accuracy:
±2% +5 Digits
Weight:
540g
AC Voltage Measurement Resolution:
100mV
Best AC Current Accuracy:
± 2 % +5 Digits
Safety Category Voltage:
600 V, 1000 V
Absolute Maximum DC Voltage Measurement:
1 kV dc
Height:
50mm
Safety Category:
CAT III 1000 V, CAT IV 600 V
Best DC Voltage Accuracy:
±1 % +5 Digits
DC Voltage Measurement Resolution:
100mV
Clamp Meter Type:
AC-DC Flexible Clamp Meter
Minimum Operating Temperature:
-10°C
Functions Measured:
AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Frequency, Resistance
