Dimensions:
78 x 42 x 222mm
Power Source:
Battery, Mains
DC Current Measurement Resolution:
0.01A
Maximum Conductor Size:
34mm
Width:
42mm
Battery Life:
130 h
Resistance Measurement Resolution:
100mΩ
AC Current Measurement Resolution:
0.01A
True RMS:
Yes
Absolute Maximum AC Voltage Measurement:
1000V ac
Model Number:
F205
Best AC Voltage Accuracy:
±(1% rdg + 3digits)
Absolute Maximum AC Current Measurement:
600A ac
Battery Type:
9V 6LR61
Absolute Maximum Resistance Measurement:
59.99kΩ
Maximum Operating Temperature:
+55°C
Jaw Capacity Busbars:
34mm
Safety Category Level:
CAT IV
Length:
78mm
Absolute Maximum DC Current Measurement:
900A dc
Display Type:
Backlit LCD
Best Resistance Measurement Accuracy:
±1 % + 5 digits
Best DC Current Accuracy:
±(1% rdg + 3digits)
Weight:
354g
AC Voltage Measurement Resolution:
0.01V
Best AC Current Accuracy:
±(1% rdg + 3digits)
Safety Category Voltage:
600V
Absolute Maximum DC Voltage Measurement:
1000V dc
Height:
222mm
Safety Category:
CAT III 1000 V, CAT IV 600 V
Best DC Voltage Accuracy:
±(1% rdg + 3digits)
DC Voltage Measurement Resolution:
0.01V
Clamp Meter Type:
AC/DC Clamp Meter
Functions Measured:
AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Diode, Frequency, Harmonics, In-Rush Current, Phase rotation, Power, Power Factor, Resistance
