Width:
37mm
Height:
210mm
Length:
70mm
Weight:
200g
True RMS:
Yes
Calibrated:
RSCAL
Dimensions:
70 x 37 x 210mm
Battery Type:
9V
Display Type:
Backlight
Power Source:
Battery
Safety Category:
CAT III 600V
Clamp Meter Type:
Mini AC/DC Clamp Meter
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Duty Cycle, Frequency, Resistance, Temperature
Jaw Capacity Busbars:
20mm
Safety Category Level:
CAT III
Safety Category Voltage:
600V
Best AC Current Accuracy:
±2.5 %
Best AC Voltage Accuracy:
±2 %
Best DC Current Accuracy:
±2.5 %
Best DC Voltage Accuracy:
±1.5 %
AC Current Measurement Resolution:
1mA
AC Voltage Measurement Resolution:
0.1mV
DC Current Measurement Resolution:
1mA
DC Voltage Measurement Resolution:
0.1mV
Resistance Measurement Resolution:
100mΩ
Temperature Measurement Resolution:
0.1°C
Best Resistance Measurement Accuracy:
±1.5 %
Best Temperature Measurement Accuracy:
±2 °C
Absolute Maximum AC Current Measurement:
80A ac
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum DC Current Measurement:
80A dc
Absolute Maximum DC Voltage Measurement:
600V dc
Absolute Maximum Resistance Measurement:
40MΩ
Absolute Maximum Temperature Measurement:
+760°C
