Dimensions:
258 x 103 x 55mm
Power Source:
Battery
DC Current Measurement Resolution:
10000µA dc
Maximum Conductor Size:
40mm
Width:
103mm
Battery Life:
50 h
Resistance Measurement Resolution:
0.01Ω
AC Current Measurement Resolution:
0.01A ac
Best Temperature Measurement Accuracy:
±(1.0% + 3°C)
True RMS:
Yes
Model Number:
DPM1000
Best AC Voltage Accuracy:
±(1.5% + 5d)
Absolute Maximum AC Current Measurement:
1kA ac
Absolute Maximum Temperature Measurement:
+1000°C
Battery Type:
LR03 1.5V
Absolute Maximum Resistance Measurement:
100000Ω
Maximum Operating Temperature:
+50°C
Non-Contact Voltage Detector:
Yes
Minimum Operating Temperature:
0°C
AC Voltage Measurement Resolution:
0.01V ac
Length:
258mm
Temperature Measurement Resolution:
0.1°C
Best DC Current Accuracy:
±(1.5% + 5d)
Absolute Maximum DC Current Measurement:
1kA dc
Display Type:
LCD
Best Resistance Measurement Accuracy:
±(1.0% + 5d)
Jaw Capacity Busbars:
61 x 12mm
Weight:
600g
Best AC Current Accuracy:
±(1.5% + 5d)
Safety Category Voltage:
8000V
Absolute Maximum DC Voltage Measurement:
1000V dc
Height:
55mm
Safety Category:
CAT IV
Best DC Voltage Accuracy:
±(0.7% + 2d)
DC Voltage Measurement Resolution:
0.01V dc
Clamp Meter Type:
Power Clamp
Absolute Maximum AC Voltage Measurement:
1000V ac
