HTSUS:
8541.41.0000
RoHS Status:
ROHS3 Compliant
Viewing Angle:
120°
Package / Case:
TO-252-3, DPak (2 Leads + Tab), SC-63
Current - Test:
350mA Red, 350mA Green, 350mA Blue
Current - Max:
350mA Red, 350mA Green, 350mA Blue
Height - Seated (Max):
0.134" (3.40mm)
REACH Status:
REACH Unaffected
Thermal Resistance of Package:
23°C/W Red, 20°C/W Green, 20°C/W Blue
Luminous Flux @ Current/Temperature:
40lm Red, 85lm Green, 22lm Blue
Package:
Tape & Reel (TR)
Size / Dimension:
0.335" L x 0.335" W (8.50mm x 8.50mm)
Temperature - Test:
25°C
Voltage - Forward (Vf) (Typ):
2.1V Red, 3.2V Green, 3.2V Blue
Moisture Sensitivity Level (MSL):
5A (24 Hours)
Mounting Type:
Surface Mount
Color:
Red, Green, Blue (RGB)
Series:
Moonstone™
Supplier Device Package:
-
Lumens/Watt @ Current - Test:
54 lm/W Red, 76 lm/W Green, 20 lm/W Blue
Wavelength:
625nm Red, 525nm Green, 460nm Blue
Base Product Number:
ASMT-MT00
ECCN:
EAR99
