Typical Dual Supply Voltage:
±15V
Comparator Type:
General Purpose
Dimensions:
5 x 4 x 1.65mm
Mounting Type:
Surface Mount
Power Supply Type:
Dual, Single
Number of Channels per Chip:
1
Typical Single Supply Voltage:
5 V
Output Type:
TTL
Height:
1.65mm
Width:
4mm
Length:
5mm
Package Type:
SOIC
Minimum Operating Temperature:
-40 °C
Typical Response Time:
200ns
Typical Voltage Gain:
200 V/mV
Maximum Operating Temperature:
+105 °C
Pin Count:
8
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Current - Input Bias (Max):
0.1µA @ ±15V
Current - Quiescent (Max):
6mA
Operating Temperature:
-40°C ~ 105°C
Voltage - Supply, Single/Dual (±):
5V ~ 30V, ±2.5V ~ 15V
Package / Case:
8-SOIC (0.154", 3.90mm Width)
Type:
General Purpose
Propagation Delay (Max):
-
REACH Status:
REACH Unaffected
Output Type:
DTL, MOS, Open-Collector, Open-Emitter, RTL, TTL
Hysteresis:
-
CMRR, PSRR (Typ):
-
Package:
Tape & Reel (TR)
Voltage - Input Offset (Max):
3mV @ ±15V
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - Output (Typ):
50mA
standardLeadTime:
26 Weeks
Mounting Type:
Surface Mount
Series:
-
Supplier Device Package:
8-SOIC
Number of Elements:
1
Base Product Number:
LM211
ECCN:
EAR99
