Comparator Type:
General Purpose
Dimensions:
10.16 x 7.11 x 5.08mm
Mounting Type:
Through Hole
Power Supply Type:
Single
Number of Channels per Chip:
1
Typical Single Supply Voltage:
5 V
Output Type:
Open Collector, Open Drain
Height:
5.08mm
Width:
7.11mm
Length:
10.16mm
Package Type:
CDIP
Minimum Operating Temperature:
-55 °C
Typical Response Time:
115 ns, 165 ns
Maximum Operating Temperature:
+125 °C
Pin Count:
8
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Current - Input Bias (Max):
0.1µA @ ±15V
Operating Temperature:
-55°C ~ 125°C
Voltage - Supply, Single/Dual (±):
3.5V ~ 30V, ±1.75V ~ 15V
Package / Case:
8-CDIP (0.300", 7.62mm)
Type:
Differential
Propagation Delay (Max):
165ns (Typ)
Current - Quiescent (Max):
5mA, 6mA
Output Type:
Open-Collector, Open-Emitter
Hysteresis:
-
CMRR, PSRR (Typ):
-
Package:
Tube
Voltage - Input Offset (Max):
3mV @ ±15V
Moisture Sensitivity Level (MSL):
Not Applicable
Current - Output (Typ):
-
Mounting Type:
Through Hole
Series:
-
Supplier Device Package:
8-CDIP
Number of Elements:
1
ECCN:
EAR99
