Typical Dual Supply Voltage:
±1 → ±18V
Comparator Type:
General Purpose
Dimensions:
19.94 x 7.62 x 3.56mm
Mounting Type:
Through Hole
Power Supply Type:
Dual, Single
Number of Channels per Chip:
4
Typical Single Supply Voltage:
2 → 36 V
Output Type:
Open Collector, Open Drain
Height:
3.56mm
Width:
7.62mm
Length:
19.94mm
Package Type:
CDIP
Minimum Operating Temperature:
-55 °C
Typical Response Time:
1.3µs
Typical Voltage Gain:
200 V/mV
Maximum Operating Temperature:
+125 °C
Pin Count:
14
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Current - Input Bias (Max):
0.1µA @ 5V
Operating Temperature:
-55°C ~ 125°C
Voltage - Supply, Single/Dual (±):
5V ~ 30V, ±2.5V ~ 15V
Package / Case:
14-CDIP (0.300", 7.62mm)
Type:
Differential
Propagation Delay (Max):
1.3µs (Typ)
Current - Quiescent (Max):
2mA
Output Type:
Open-Collector, CMOS, DTL, ECL, MOS, TTL
Hysteresis:
10mV
CMRR, PSRR (Typ):
70dB CMRR, 70dB PSRR
Package:
Tube
Voltage - Input Offset (Max):
2mV @ 30V
Moisture Sensitivity Level (MSL):
Not Applicable
Current - Output (Typ):
20mA
Mounting Type:
Through Hole
Series:
-
Supplier Device Package:
14-CDIP
Number of Elements:
4
ECCN:
EAR99
