Typical Dual Supply Voltage:
±2.7 → ±5V
Comparator Type:
General Purpose
Dimensions:
3.1 x 3.1 x 0.95mm
Mounting Type:
Surface Mount
Power Supply Type:
Dual, Single
Number of Channels per Chip:
2
Typical Single Supply Voltage:
2.7 → 5 V
Output Type:
Open Drain
Height:
0.95mm
Width:
3.1mm
Length:
3.1mm
Package Type:
MSOP
Minimum Operating Temperature:
-40 °C
Typical Response Time:
800ns
Typical Voltage Gain:
50 V/mV
Maximum Operating Temperature:
+85 °C
Pin Count:
8
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Current - Input Bias (Max):
0.001µA @ 5V
Current - Quiescent (Max):
250µA
Operating Temperature:
-
Voltage - Supply, Single/Dual (±):
2.7V ~ 5V
Package / Case:
8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
Type:
General Purpose
Propagation Delay (Max):
1.5µs
REACH Status:
REACH Unaffected
Output Type:
Open Drain
Hysteresis:
-
CMRR, PSRR (Typ):
-
Package:
Tape & Reel (TR)
Voltage - Input Offset (Max):
9mV @ 5V
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - Output (Typ):
84mA @ 5V
standardLeadTime:
34 Weeks
Mounting Type:
Surface Mount
Series:
-
Supplier Device Package:
8-MSOP
Number of Elements:
2
Base Product Number:
LMV393
ECCN:
EAR99
