Depth:
92mm
Width:
45 mm
Length:
85mm
Series:
LC1D
Function:
Motor Control
Mount Type:
DIN Rail
Coil Voltage:
48 V ac
Power Rating:
18.5kW
Product Type:
Contactor
Terminal Type:
Screw
Contact Current:
38A
Contact Voltage:
440V
Number of Poles:
3
Standards/Approvals:
RoHS, CCC, CSA, EAC, EN 60947-5-1, IEC, UL
Better World Product:
Yes
Contactor Application:
Motor Control, Resistive Load
Operational Current Ie:
38A
Control Circuit Voltage Uc:
48 V
Normal State Configuration:
3 NO
Number of Auxiliary Contacts:
2
Pole and Throw Configuration:
3
Maximum Operating Temperature:
60°C
Minimum Operating Temperature:
-40°C
Auxiliary Contact Configuration:
1 NO/1 NC
Better World Verification:
Green Premium
Better World Product:
Yes
Maximum Operating Temperature:
+60°C
Contact Current Rating:
38 A
Series:
LC1D
Minimum Operating Temperature:
-5°C
Coil Voltage:
48 V ac
Length:
85mm
Width:
45mm
Depth:
92mm
Number Of Auxiliary Contacts:
2
Normal State Configuration:
3NO
Range:
TeSys D
Auxiliary Contact Configuration:
1NO + 1NC
Power Rating:
18.5 kW
Contact Voltage Rating:
440 V ac
Number of Poles:
3
Terminal Type:
Screw
