Depth:
57mm
Width:
45 mm
Length:
58mm
Series:
LC1K
Function:
Motor Control
Mount Type:
DIN Rail
Coil Voltage:
24 V ac
Power Rating:
5.5kW
Product Type:
Contactor
Terminal Type:
Screw
Contact Current:
12A
Contact Voltage:
690V
Number of Poles:
3
Standards/Approvals:
CCC, CSA, EAC, RoHS, UL, IEC
Better World Product:
Yes
Contactor Application:
Motor Control, Resistive Load
Operational Current Ie:
20A
Control Circuit Voltage Uc:
24 V
Normal State Configuration:
3 NO
Number of Auxiliary Contacts:
1
Pole and Throw Configuration:
3
Maximum Operating Temperature:
50°C
Minimum Operating Temperature:
-25°C
Auxiliary Contact Configuration:
1 NO
Better World Verification:
Green Premium
Better World Product:
Yes
Maximum Operating Temperature:
+50°C
Contact Current Rating:
12 A
Series:
LC1K
Minimum Operating Temperature:
-25°C
Coil Voltage:
24 V ac
Length:
58mm
Width:
45mm
Depth:
57mm
Number Of Auxiliary Contacts:
1
Normal State Configuration:
3NO
Range:
TeSys K
Power Rating:
5.5 kW
Contact Voltage Rating:
690 V ac
Number of Poles:
3
Terminal Type:
Screw
