Depth:
57mm
Width:
45 mm
Length:
58mm
Series:
CA3KN
Function:
Control Relay
Mount Type:
DIN Rail
Coil Voltage:
24 V
Product Type:
Contactor
Terminal Type:
Screw Clamp
Contact Current:
10A
Contact Voltage:
690V
Number of Poles:
4
Standards/Approvals:
CCC, CB scheme, JIS C8201-4-1, EN/IEC 60947-4-1, EAC, CSA C22.2 No 60947-4-1, CSA, CE, UL 60947-4-1, UL, UKCA, RoHS, REACH, GB/T 14048.4, WEEE
Better World Product:
Yes
Distrelec Product Id:
30112050
Contactor Application:
Control Circuit
Control Circuit Voltage Uc:
24 V
Normal State Configuration:
2 NO/2 NC
Number of Auxiliary Contacts:
4
Pole and Throw Configuration:
4
Maximum Operating Temperature:
50°C
Minimum Operating Temperature:
-25°C
Auxiliary Contact Configuration:
2 NO/2 NC
